SlimLED Original
Product Details
|
Description
|
SlimLED Original
|
|
Part #
|
MASTER_SLM_CCT
|
A slender, low-profile downlight that not only excels in performance but also makes residential installation a breeze. This downlight solution offers impressive light output, energy efficiency and a modern, streamlined design. Made to excel even in wet locations.
Nominal Size
Finish Color
Feature List
Body
Durable airtight aluminum body with UV stable paint and white PMMA diffuser lens for low glare. Includes silicone gasket for wet location applications.
LED Characteristics
This general application light fixture features a 7 watt LED module that maintains uniform intensity producing up to 505 lumens; with a typical CRI of 90. Available with 5 step CCT switch on the driver (2700 K, 3000 K, 3500 K, 4000 K and 5000 K).
Dimming
100%-10% dimming capability. This fixture is compatible with industry standard forward/reverse phase or TRIAC/ELV dimmers.
Beam Spread
The fixture lens provides 110° beam spread.
Mounting
Includes two spring loaded clips to attached to any ceiling material. The slim profile allows to be mounted under joists or duct work.
LED Driver
Steel hardwire box with 170mA dimmable class II electronic LED driver with 100-135V AC input. Includes an 18" plenum rated FT4 wire with DC 2.1 connector from driver to fixture.
Quick Connect push-in terminals
"Quick connect" push-in terminals for fast and easy wiring.
Operating Temperature
-30°C~35°C (-22°F~95°F)
Environment
- Suitable for wet locations.
- Suitable for insulated ceiling applications.
- Indoor/outdoor
Accessories
Please select a specific item to view its accessories
Specifications
| Finish Color | White, Black |
| Beam Distribution | Wide (> 40°) |
| Luminaire Type | Recessed |
| Product Family | SlimLED |
